Kurven · Curves · Courbes

1

KR=R 2

3

L 1
4

5

MA=A 6
b
L 2
7

00128659
8

Kurve KU 1/180 9
Curve
30 kg Courbe
b 1) L , L 2 v N 2) U,f KR MA 3) Nr./No./N° 10
1
[mm] [mm] [m/min]  11-58ff
 11-58ff
80 0; 150...5000 0; 6; 9; 12; 15; 18 L; R A 3 842 999 987 11
120 0; 150...5000 0; 6; 9; 12; 15; 18 L; R A b = ... mm
160 0; 150...5000 0; 6; 9; 12; 15; 18 L; R A L 1 = ... mm
L 2 = ... mm 12
v = ... m/min
N
U = ... V
f = ... Hz 13
KR = ...
MA = ...
14
  
1) b = Spurbreite in Transportrichtung 1) b = Track width in direction of transport 1) b = Ecartement de voie en direc. du transport

2) v = Nenngeschwindigkeit 2) v = Nominal speed 2) v = Vitesse nominale 15
N
N
N
3) Motoranbau A = außen 3) Motor mounting A = outside 3) Montage du moteur A = extérieur
16
