Page 61 - TS1_5.4

3 842 528 596 (2018-02) TS 1 5.4 Bosch Rexroth AG 4–11

Kurven · Curves · Courbes

1

MA=A
KR=R 2
AE=1 g
3

4

g
5

6
L 1

7

00128656
8

Kurve KU 1/360 9
Curve
30 kg Courbe
b 1) AE 4) L 1 v N 2) U,f KR MA 3) Nr./No./N° 10
[mm] [mm] [m/min]  11-58ff
 11-58ff
80 1; 2 150...5000 0; 6; 9; 12; 15; 18 L; R A 3 842 999 988 11
120 1; 2 150...5000 0; 6; 9; 12; 15; 18 L; R A b = ... mm
160 1; 2 150...5000 0; 6; 9; 12; 15; 18 L; R A AE = ...
L = ... mm 12
1
v = ... m/min
N
U = ... V
f = ... Hz 13
KR = ...
MA = ...
14
  
1) b = Spurbreite in Transportrichtung 1) b = Track width in direction of transport 1) b = Ecartement de voie en direc. du transport

2) v = Nenngeschwindigkeit 2) v = Nominal speed 2) v = Vitesse nominale 15
N
N
N
3) Motoranbau A = außen 3) Motor mounting A = outside 3) Montage du moteur A = extérieur
4) AE = 1: 1 Antrieb; AE = 2: 2 Antriebe 4) AE = 1: 1 drive; AE = 2: 2 drives 4) AE = 1 : 1 entraînement ;
AE = 2 : 2 entraînements 16
