Page 57 - TS1_5.4

3 842 528 596 (2018-02) TS 1 5.4 Bosch Rexroth AG 4–7

Kurven · Curves · Courbes

1

2

3
L 1

4
KR=R

5

L 2
6

MA=A
7

b
8
00128662

Kurve KU 1/90 9
Curve
30 kg Courbe
b 1) L , L 2 v N 2) U,f KR MA 3) Nr./No./N° 10
1
[mm] [mm] [m/min]  11-58ff
 11-58ff
80 0; 150...5000 0; 6; 9; 12; 15; 18 L; R I; A 3 842 999 986 11
120 0; 150...5000 0; 6; 9; 12; 15; 18 L; R I; A b = ... mm
160 0; 150...5000 0; 6; 9; 12; 15; 18 L; R I; A L = ... mm
1
L = ... mm 12
2
v = ... m/min
N
U = ... V
f = ... Hz 13
KR = ...
MA = ...
14
  
1) b = Spurbreite in Transportrichtung 1) b = Track width in direction of transport 1) b = Ecartement de voie en direc. du transport

2) v = Nenngeschwindigkeit 2) v = Nominal speed 2) v = Vitesse nominale 15
N
N

N
3) Motoranbau A = außen, I = innen 3) Motor mounting A = outside, I = inside 3) Montage du moteur A = extérieur, I = intérieur
