8-118 TS 2plus 8.0 | Transportsteuerung
Sensor-Anwendungsmatrix

Sensor-Anwendungsmatrix
Durchmesser mit Sensor
Steckanschluss
M12 mit M12 3842557633 3842501548 3842549814 3842558990
S N = 8 mm S N = 4 mm S N = 4 mm S N = 8 mm
L = 45 mm L = 70 mm L = 45 mm L = 60 mm
M12 mit M8 3842549813 3842549812 3842549811
S N = 8 mm S N = 4 mm S N = 4 mm
L = 44 mm L = 67 mm L = 44 mm
M8 mit M8 3842551761
S N = 2 mm
L = 30 mm
Stellungs abfrage AS 2/C-100,
AS 2/C-250 X
AS 2/C-400, X
AS 2/C-700
AS 2/R-300, X
AS 2/R-700
AS 2/R-1200, X
AS 2/R-2200
AS 2/R-V-1200, X
AS 2/R-V-2200
BS 2/R-300, X
BS 2/R-700
BS 2/C-100, X
BS 2/C-250
BS 2/R-H X
BS 2/R-V-1200 X
BS 2/C-H X
CS/C X
EQ 2/TR X
EQ 2/TR-90 X
EQ 2/T X
EQ 2/TE X
HQ 2/S X
HQ 2/O X
HQ 2/T X
HQ 2/U X
HQ 2/U2 X
HQ 2/U-H X
HQ 2/C-H X
HQ 2/G-H X
HD 2 X
HD 2/H X
KU 2/… X
PE 2 X
PE 2/X, PE 2/H X
PE 2/XP X
HP 2/L X
HP 2 X
Stellungs abfrage X
VE 2
VA 2/D-130 X
